SPF & Include Tag Recursion

What happens when SPF includes nest too deeply?

You’ve configured SPF correctly. Your domains align. Yet emails still fail validation. Why? Because SPF isn’t just about your record—it’s about what’s inside it.

SPF records use <include> directives to reference other policies. But if those includes chain too deep, each one triggers a new DNS lookup. When the total exceeds 10 queries—common with nested includes—DNS resolvers cut off the request. SPF validation fails. Your email gets rejected or marked spam, even if your setup is technically flawless.

This is how include tag recursion affects SPF mechanism performance: a well-intentioned configuration can break delivery simply because the DNS resolver hit its limit. It’s not a typo. It’s not misconfiguration. It’s a hidden performance ceiling.

Key takeaways

Each <include> in an SPF record triggers a separate DNS lookup, increasing the total query count.
Most DNS resolvers limit the number of DNS queries during SPF validation to 10; exceeding this causes validation failure.
Nested or recursive <include> tags can quickly exhaust the 10-query limit, leading to email delivery failure despite correct policy configuration.

How include tag recursion affects SPF mechanism performance

SPF record evaluation stops at 10 DNS queries. If your SPF includes domains that themselves include others—like A → B → C → D—you’re stacking DNS lookups. More than 10 queries break SPF, causing senders to fail alignment and risk delivery failure. This isn’t hypothetical: large organizations with complex email setups often hit this limit without realizing it.

How includes stack up in practice

Let’s say your domain’s SPF record uses include:company.com. That domain’s SPF might include include:mailer.com, which in turn includes include:smtp.provider.net. Each include triggers a separate DNS lookup. By the time you reach the fourth level, you’ve already used four queries. If other mechanisms or includes are part of the chain, you can exceed the 10-query limit faster than you think.

Each lookup must resolve, and every response adds latency. DNS resolvers enforce a hard limit of 10 queries per SPF evaluation, as defined in RFC 1035. Once that limit is reached, the SPF check stops and returns a permerror—meaning the email fails SPF validation, regardless of whether the underlying domains are valid.

The RFC specifies this behavior directly—it’s not a quirk, it’s built into the protocol. This means a single misconfigured include chain can break SPF for every email sent from your domain, even if the rest of your infrastructure is solid.

Why it matters for deliverability

You might have perfect DKIM signing, clean content, and strong sender reputation—but if SPF fails due to recursion, your emails are likely to be flagged or rejected. ISPs and mailbox providers treat SPF alignment as a gatekeeper. A failed check drops your credibility, even with minor misconfigurations.

This is especially common in enterprises with shared email infrastructures, legacy systems, or third-party vendors. You may not know your SPF includes are recursive until you start seeing bounces or low inbox placement. Tools like MailTester's email checker can validate SPF chains in real time, identifying recursive includes before they cause delivery issues.

Let's be clear: SPF recursion isn’t a bug—it’s a design constraint. But it becomes a failure point when teams don’t audit their DNS records. The fix is simple: review your SPF chains, avoid deep includes, and prefer alignment with SPF’s 10-query limit. If you're validating thousands of addresses, consider bulk verification with MailTester's list verification to catch SPF-related issues at scale.

Why recursion is a silent deliverability killer

SPF recursion fails silently—no bounce, no alert, just a missed email. When SPF checks chain too deeply, servers reject the message outright or flag it as spam. This can happen even with minor misconfigurations, especially when third-party tools or legacy systems add extra DNS lookups. The result? Emails vanish into junk folders or are blocked at the gate, without a single error message pointing to SPF as the culprit.

How recursion breaks SPF validation

SPF relies on a strict limit: no more than 10 DNS lookups per validation. Each include tag adds a lookup. If you include multiple third-party services—each with their own include or redirect—you can hit that limit in seconds. The server gives up, reports a fail, and the email is rejected.

Let’s say you include your CRM, ESP, marketing platform, and vendor support system—all with SPF records. Each one may include another domain. This chains together. Even if each one looks valid individually, the cumulative chain breaks SPF. The mail server sees too many lookups and halts the process.

Why it goes unnoticed

No bounce message says “SPF failed due to recursion.” You don’t see an error like “Invalid SPF.” The message just doesn’t land in the inbox. It might end up in spam, or worse—never acknowledged by the recipient server at all.

This is why delivery issues often go undiagnosed. Teams check blacklists, sender reputation, or content filters—but never realize a hidden SPF limit was breached by nested include tags. The problem isn’t in the content, the domain, or the sending IP. It’s in the DNS chain.

Some organizations see 15–20% of emails fail inbox delivery for reasons they can’t trace. When you dig into the headers, the root cause is often SPF recursion. According to RFC 7208, SPF limits are fixed: a chain of too many include tags violates the standard. The email is rejected at the wire, before it ever reaches the recipient’s mailbox.

You can’t fix what you don’t see. But you can test for it. Use tools that simulate real-world validation—not just syntax checks. MailTester’s inbox placement tester checks how your messages perform across real domains, including SPF validation, to show where they fail before sending.

Real-world example: The case of a nested shared hosting setup

When SPF records reference domains in a circular chain—like an ESP pointing to a parent, which includes a CDN that points back to the ESP—the DNS resolver detects the loop early and halts evaluation before hitting the 10-domain limit. This breaks SPF validation entirely, even if the chain is otherwise valid.

The Problem in Practice

Let’s say your marketing team uses an ESP (email service provider) that has an SPF record including your parent domain: include:_spf.parent.example.com.
Your parent domain, in turn, uses a CDN provider and includes that in its SPF: include:spf.cdn.provider.net.
Unbeknownst to you, the CDN provider’s SPF record includes your ESP’s domain: include:spf.esp.yourmarketing.com.
Now you have a loop: ESP → parent → CDN → ESP. DNS resolvers detect this circular reference during lookup.
As defined in RFC 7208 (Section 5.1), when a DNS resolver encounters a loop, it stops evaluating that chain. It doesn't count toward the 10-dedicated-include limit—it simply fails the check.
Result? The SPF record is invalid, even if it contains no more than ten includes. Your domain fails SPF authentication, and your emails risk being rejected or marked as spam.

Why This Matters for Deliverability

The real danger isn’t the number of includes—it’s the structure. A correctly configured SPF record should allow valid inclusions without loops. But when domains share infrastructure across multiple layers (like shared hosting, CDNs, or third-party providers), these loops emerge unexpectedly. According to the IETF’s RFC 7208, SPF evaluation must stop on a detected loop to prevent infinite recursion and security risks.

The 6 steps described in “The Problem in Practice”, in order.

Even with a proper SPF alignment, if your ESP or CDN provider uses a recursive include chain, your reputation suffers. You can’t fix it at runtime—only by auditing configurations at every layer. This is why tools that test SPF structure in isolation help prevent these issues before deployment.

For teams relying on third-party services, running a full SPF chain assessment is non-negotiable. One misconfigured include can break deliverability for your entire domain.

Verify your domain's SPF structure with tools that analyze includes and detect loops—before your campaigns get filtered.

How to detect and fix SPF recursion

SPF recursion occurs whendirectives create circular references or deeply nested chains, causing DNS lookup failures and breaking email authentication. This can result in delivery failures or spam filtering. You can detect it by tracing SPF records manually or with tools that simulate full DNS resolution, then fix it by eliminating circular includes or simplifying nested policies.

Spot the recursion

Use dig txt yourdomain.com or host -t txt yourdomain.com to fetch your SPF record and trace alldirectives.
For eachvalue, fetch its SPF record separately and check if it contains furthertags — repeat until you find a loop.
Look for circular patterns: domain A includes B, and B includes A. This is a direct SPF failure and will break authentication.
Check for deeply nested chains where multiple domains include each other in a sequence that exceeds normal resolution depth (typically 10 levels).

Verify with full chain simulation

Use a tool that simulates the entire DNS chain traversal, like the SPF validation features in MxToolbox or RFC 7208, which defines SPF’s maximum include depth.
These tools report query depth, loop detection, and resolution failure points, making it easy to isolate problematic includes.
Manually inspect every domain in your include chain to ensure no recursive dependencies exist.
Once identified, replace problematic includes with direct mechanisms like include:trusted-reputation-provider.com where applicable, or remove redundant includes entirely.

SPF recursion isn’t just a technical quirk — it's a deliverability risk. A single circular reference can cause your entire domain’s SPF to fail.

Once fixed, revalidate your SPF record using a tool that checks full DNS resolution. This includes checking all included domains, their policies, and verifying that no chain exceeds standard limits. Tools like MailTester’s bulk verification can help you check large lists for related issues like misconfigured domains or invalid email structures that compound deliverability problems.

The role of email verification in catching SPF risks

You don’t need to parse SPF records directly to reduce SPF-related deliverability risks. Instead, email verification tools like MailTester identify domains with known misconfigurations—such as recursive SPF checks, overly complex policies, or missing alignment—before they cause bounces or spam filtering. By filtering out addresses from these problematic domains, you reduce exposure to authentication failures that hurt sender reputation and inbox placement.

How verification reveals hidden SPF exposure

SPF is designed to prevent spoofing by validating the sending server. But when domains use recursive include tags—like include:domain1.com that itself includes include:domain2.com and so on—the lookup chain can exceed the 10-lookup limit defined in RFC 7208. This causes a permanent failure, even if the sender is legitimate.

MailTester doesn’t analyze SPF records in real time. But it flags domains known for such issues based on historical delivery failures, public blocklist data, and patterns seen across verified lists. If multiple addresses in your list come from domains with broken SPF chains, it’s a red flag.

When the system detects these patterns during bulk verification, it highlights them as high-risk candidates. You can then remove them or flag the list for deeper review.

Why catching bad domains matters

SPF failures don’t always result in immediate rejection, but they do degrade sender reputation. ISPs and mailbox providers track alignment and authentication consistency. Repeated failures—even from a small percentage of your list—can trigger rate limiting or inbox placement drops.

Even if a domain’s SPF passes validation, it may still be associated with disposable addresses, greylists, or role accounts—all of which hurt deliverability. Verification helps you weed out these signals before sending.

For example, domains that rely on multiple third-party services for email routing often have tangled SPF configurations. An email checker can spot this early—especially when used as part of a pre-send workflow.

With MailTester’s bulk verification, you get a real-time snapshot of list health, including risk flags tied to reputation issues, including those linked to SPF or DKIM problems. It’s not a substitute for checking DNS records—but it’s a practical way to act on known risks without diving into technical details.

As with all deliverability safeguards, prevention beats remediation. Regularly testing your list with tools that simulate real-world sending behavior—like inbox placement testing—can reveal how badly misconfigured domains harm your reach.

Pro tip: Use SPF checkers that trace recursion depth

SPF include tag recursion can fail silently after more than 10 levels, even if your DNS resolves. Tools that track recursion depth warn you before the limit, spot circular includes, and catch configuration errors that would otherwise cause send failures. Always validate SPF with a checker that logs the full query chain.

Why recursion depth matters

Each include in an SPF record triggers a DNS lookup. The DNS standard (RFC 4408) caps this at 10 queries per SPF evaluation. Go beyond that, and your email fails SPF validation — even if all domains are reachable. Many senders never see this because they don’t track the full chain.

Let’s say your SPF includes include:spf.example.com, which itself includes include:spf.partner.net, and that one loops back to your domain. Without deep tracing, you won’t know. This circular dependency isn’t caught by basic validators — but advanced ones detect these loops early and report them.

Some SPF checkers, like those in MailTester’s email validation suite, track every DNS fetch during SPF evaluation. They list the full chain of includes and flag any path exceeding eight steps — well before the hard limit. This helps you avoid surprises in production.

According to the RFC, SPF record evaluation ends at 10 include queries. Beyond that, the result is “soft fail” or “permfail,” meaning your emails are likely rejected or marked as spam. Prevent this by testing SPF configurations with tools that reveal recursion depth and loop patterns.

What to look for in an SPF checker

Not all SPF validators are equal. Basic ones only return “pass” or “fail” without context. The best ones show you the resolution path — which domains were queried and in what order. That clarity lets you see where a chain breaks or loops.

You’re better off using a service that integrates SPF analysis into broader email validation — like MailTester’s bulk verification, which checks SPF, DNS, and deliverability in one flow. It surfaces warnings for deep chains or loops before you ever send.

If you’re building at scale, use the SPF-aware verification API to validate sender configurations programmatically. It’s not just about catching single bad addresses — it’s about ensuring your entire infrastructure respects DNS query limits and avoids circular dependencies.

Best practices for SPF record design

You should avoid chaining multiple <include> statements in your SPF record, as each one increases DNS lookup count and risks hitting the 10-query limit. Place <all> only at the end, never before an <include>, and prefer centralized, well-managed domains for shared services. Use a single domain to manage common senders, and validate your record with tools like MXToolbox or the SPF debugger in MailTester before deploying.

Key rules for SPF record stability

Limit the number of <include> directives to essential, high-trust domains only — avoid chaining them across multiple third parties.
Use <spf4> or direct mechanisms (like <ip4> or <ip6>) for known IP ranges instead of relying on nested includes.
Always place <all> at the very end of the record. Putting it earlier invalidates everything that follows, even valid includes.
Keep total DNS lookups under 10. Each <include> counts toward this limit — overages result in a neutral or soft fail.
Never include an SPF record from a domain that itself includes another — this creates dependency loops or excessive lookups.

Design for control and simplicity

Use one centralized domain (e.g. spf.company.com) to manage shared services like marketing or support platforms. This reduces complexity and ensures consistent policies.
Avoid cross-including from multiple sources (e.g. a marketing tool including a support domain that includes another). This creates fragility and tracking issues.
Test your SPF record before deployment using free tools like MXToolbox’s SPF checker or RFC 7208’s validation guidelines.
If you manage a large email list, test your sender’s deliverability using inbox placement testing to catch SPF-related issues early.

Let’s be clear: SPF is not about complexity. It’s about precision. A single invalid include can break your entire sending policy. The best SPF records are simple, centralized, and verifiable — not layered with endless includes just to check a box.

You can catch SPF recursion issues before they hurt deliverability by verifying email lists with real-time SMTP checks and DNS analysis. MailTester identifies domains with flawed SPF configurations—even when individual addresses are technically valid—so you avoid sending to high-risk inboxes. This catches problems early, before they trigger bounces, blacklists, or inbox placement drops.

Spotting SPF issues through DNS and SMTP validation

SPF recursion happens when a domain’s SPF record references other domains with their own SPF records, creating loops or excessive lookups. This can cause delivery failures, especially with strict filtering systems. MailTester checks each address using real SMTP connections and analyzes the domain’s DNS—specifically SPF, DKIM, and DMARC records—to flag misconfigurations that could block your message.

Even if an email address is syntactically valid, a broken SPF setup means the receiving server may reject it. MailTester surfaces these risks by detecting known patterns of SPF recursion, alignment failures, or overly complex SPF chains. This helps you filter out addresses from domains that will likely fail delivery due to policy issues—not just invalid syntax.

Identifying and reacting to list-wide patterns

When you run a bulk verification, MailTester reveals trends across your list. If 10% of your recipients come from domains with SPF recursion or other deliverability red flags, that’s a sign something’s wrong with your source data. It’s not just about one bad address—it’s about systemic risk.

Let’s say you’re sending to 10,000 contacts. If 1,000 come from domains with known SPF issues, your sender reputation takes a hit, even if those addresses are valid. MailTester helps you see these patterns in real time, so you can clean your list before sending.

When you use the in-app AI assistant, it can recommend removing or flagging addresses from such domains. It’s not just about scrubbing invalid addresses—it’s about avoiding the cost of sending to domains that will fail delivery due to policy, not syntax.

For real-time checks on individual addresses, use the email checker. For large campaigns, bulk verification gives full visibility. With integrations into platforms like Mailchimp or HubSpot, you can automate the cleanup before sending. And while SPF recursion itself isn’t always a hard rejection, it’s a well-documented contributor to filtering, as noted in RFC 7208.

What happens if you ignore SPF recursion?

Ignoring SPF recursion leads to broken authentication chains, causing emails from affected domains to land in spam folders or be rejected outright by receiving servers.

Sender reputation suffers long-term damage—especially when hundreds or thousands of messages are blocked. Recovery can take weeks or months, depending on the volume and consistency of failures.

Impact on deliverability

Some ISPs deliver messages despite SPF failures, but stricter filters apply blacklisting rules, reducing inbox placement by up to 40%.
High-volume senders with poorly structured SPF records face systemic deliverability breakdowns due to recursive validation errors.
As list size increases, so does the risk of cascading SPF validation failures across subdomains and third-party services.

Sources

DMARC adoption among top domains surged 75% between 2023 and 2025 — from 27.2% to 47.7% — in the wake of Google and Yahoo's bulk-sender authentication requirements. — EasyDMARC 2025 DMARC Adoption Report (2025)
Since May 5, 2025, Microsoft Outlook requires SPF, DKIM, and DMARC from domains sending 5,000+ emails per day, rejecting non-compliant mail outright at the SMTP level with error 550 5.7.515. — Microsoft Outlook requirements (via MailOver bulk-sender requirements guide) (2025)

Keep reading

Ready to put this into practice? MailTester verifies emails with 98.9% accuracy — start with 100 free verifications.

Frequently asked questions

What is SPF recursion?

SPF recursion occurs when an SPF record includes another domain that itself includes another, creating a chain of DNS lookups that can exceed the 10-query limit.

How many DNS queries does SPF allow?

Most DNS resolvers limit SPF evaluations to 10 DNS queries. Exceeding this causes the SPF check to fail.

Can SPF recursion cause emails to be rejected?

Yes. If recursive includes exceed the 10-query limit, SPF validation fails, and the email may be rejected or marked as spam.

Is there a tool to test for SPF recursion?

Yes. Tools like MxToolbox, SPF Survey, and DNS lookup utilities can trace the full DNS chain and flag deep nesting or loops.

Can MailTester detect SPF problems?

MailTester does not analyze SPF records directly, but it identifies domains with known deliverability issues, including misconfigured SPF.

What is an SPF loop?

An SPF loop occurs when domain A includes B, and B includes A, creating a circular dependency that prevents DNS resolution.

Does every include tag count as a DNS query?

Yes. Each <include> directive triggers a separate DNS lookup. Multiple includes compound the query count.

Why do some emails fail SPF even with valid domains?

Because of recursive includes that exceed the DNS query limit, even if all individual domains are correct.

How do I reduce my SPF query count?

Limit include statements, avoid nesting, use centralized domains, and test your record with a DNS trace tool.

Can I fix SPF recursion without changing my email provider?

Yes. You can simplify your SPF by removing unnecessary includes or using a unified, less recursive configuration.

Does DKIM or DMARC help if SPF fails?

DKIM and DMARC provide additional authentication layers, but SPF failure alone can still lead to delivery problems.

What’s the impact on sender reputation?

Persistent SPF failures hurt sender reputation, reducing inbox placement and increasing spam complaints over time.
